90 Degree Female Thread Elbow Fitting

As a professional manufacturer in China, Shenchi’s 90 Degree Female Thread Elbow Fitting is engineered specifically to facilitate the transition between threaded rigid pipes and flexible hoses, enabling a 90-degree directional change in piping layouts.

Its female-threaded end can be securely screwed onto faucets, male-threaded fittings, or metal pipes, ensuring a leak-proof seal within the rigid piping system.

The barbed end is designed to be inserted directly into the inner bore of rubber hoses, braided hoses, or PVC flexible tubing; the surface's serrated structure grips the inner wall of the hose, creating a secure, pressure-resistant, and anti-slip seal when fastened with a hose clamp or jubilee clip.

This design eliminates the need for threading the hose end or using complex tools, thereby significantly boosting installation efficiency for various equipment connections (such as washing machine faucets, garden hoses, and industrial equipment interfaces). Corrosion-resistant and capable of withstanding high pressure, this product is widely applicable in residential, commercial, and industrial settings for rigid-to-flexible hose water supply systems.

Product Specifications

The Shenchi 90 Degree Female Thread Elbow Fitting is a specialized component designed to professionally facilitate the transition between rigid and flexible tubing. Available in both female-threaded and male-threaded configurations, it meets a diverse range of connection requirements:

90 Degree Female Thread Elbow Fitting: Features a female thread on one end and a barbed hose fitting on the other, designed for connection to male-threaded components.

90 Degree Male Thread Elbow Fitting: Features a male thread on one end and a barbed hose fitting on the other, designed for connection to female-threaded components.

As a specialized exporter of 90-degree threaded elbow fittings, Shenchi extends the exquisite craftsmanship embodied in this barbed elbow to its entire product line. We offer users worldwide a selection of high-quality 90-degree threaded barbed elbows—along with complementary accessories—at affordable prices.

Key Performance Advantages

1. Dual-End Asymmetrical Design: The threaded end complies with international standards, ensuring a tight seal when connected to metal pipe fittings. The barbed end features multiple annular barbs that provide a secure grip once inserted into a flexible hose; when secured with a hose clamp, it offers exceptional resistance to pull-out forces. This product is manufactured using the same rigorous process standards, ensuring consistent quality across our entire product line.

2. Fluid Dynamics Optimization: The 90-degree elbow features a large-radius flow channel design, which minimizes flow resistance and reduces pressure loss, resulting in higher fluid transmission efficiency.

3. Durable Construction: The main body is constructed from high-quality stainless steel with a corrosion-resistant surface treatment. It offers excellent weather resistance and is suitable for use with water, oil, and mildly corrosive media.

4. Versatile Application: With an operating temperature range of -20°C to 110°C and a maximum pressure rating of 2.5 MPa, the fitting maintains a reliable seal even in environments subject to alternating hot and cold cycles.

5. Easy Installation: The barbed end requires no threading; installation is completed simply by inserting the hose and tightening the hose clamp, significantly saving on both labor and time costs.

Maintenance Guidelines

1. Pre-installation Inspection: Verify that the threads are intact, the hose barb teeth are undamaged, and the inner diameter of the hose matches the size of the barb fitting.

2. Proper Installation: For the threaded end, wrap the threads with sealing tape before screwing the fitting into place. For the barbed end, slide the hose fully down to the base of the barb and secure it tightly using a stainless steel hose clamp positioned over the barb teeth. The installation procedure is identical for both the 90-degree male-threaded elbow and the 90-degree female-threaded elbow, ensuring a simple and consistent process.

3. Periodic Inspection: Conduct inspections every six months to check for leaks at the connection points, verify that the hose clamps remain tight, and look for any signs of corrosion on the threaded ends.

4. Troubleshooting: In the event of a leak, first check the tightness of the hose clamp. If the leak originates from the threaded connection, re-wrap the threads with sealing tape or replace the fitting.
